Product Description:
Dc charging pile is a device used to charge electric vehicles, which can charge the battery of electric vehicles at high speed. Unlike AC charging stations, DC charging stations can transfer electricity directly to the battery of the electric vehicle, so it can charge faster. Dc charging piles can be used not only to charge personal electric vehicles, but also for charging stations in public places. In the popularization of electric vehicles, DC charging piles also play a crucial role, which can meet the needs of users for fast charging and improve the convenience of using electric vehicles.
Product Paramenters：
|
80KW DC charging pile |
||
|
Equipment Models |
BHDC-80KW |
|
|
AC input |
Voltage range (V) |
380±15% |
|
Frequency range (Hz) |
45~66 |
|
|
Input power factor electricity |
≥0.99 |
|
|
Current harmonics (THDI) |
≤5% |
|
|
AC output |
Efficiency |
≥96% |
|
Voltage range (V) |
200~750 |
|
|
Output Power (KW) |
80 |
|
|
Maximum current (A) |
160 |
|
|
Charging interface |
1/2 |
|
|
Charge gun long (m) |
5 |
|
|
Configure Protection Information |
Noise (dB) |
<65 |
|
Steady-state accuracy |
≤±1% |
|
|
Accuracy voltage regulation |
≤±0.5% |
|
|
Output current error |
≤±1% |
|
|
Output voltage error |
≤±0.5% |
|
|
Current imbalance |
≤±5% |
|
|
Man-machine display |
7 inches color touch screen |
|
|
Charging operation |
Plug and play/scan code |
|
|
Metering charging |
DC watt-hour meter |
|
|
Operation Instruction |
Power, Charge, Fault |
|
|
Man-machine display |
Standard Communication Protocol |
|
|
Heat dissipation control |
Air Cooling |
|
|
Protection level |
IP54 |
|
|
BMS Auxiliary power supply |
12V/24V |
|
|
Reliability (MTBF) |
50000 |
|
|
Size (W*D*H) mm |
700*565*1630 |
|
|
Installation mode |
Wholeness Landing |
|
|
Routing mode |
Downline |
|
|
Worksing Environment |
Altitude (m) |
≤2000 |
|
Operating temperature(℃) |
-20~50 |
|
|
Storage temperature(℃) |
-20~70 |
|
|
Average relative humidity |
5%~95% |
|
|
Optional |
O4GWireless Communication O Charging gun 8/12m |
|
Product Application:
The use of new energy electric vehicle DC charging pile scene mainly focuses on the need for rapid charging occasions, its high efficiency, fast charging characteristics make it become an important device in the field of electric vehicle charging. The use of DC charging piles mainly focuses on occasions that require fast charging, such as public car parks, commercial centres, highways, logistics parks, electric vehicle leasing venues and the interior of enterprises and institutions. Setting up DC charging piles in these places can meet the demand of EV owners for charging speed and improve the convenience and satisfaction of EV use. Meanwhile, with the popularity of new energy electric vehicles and the continuous development of charging technology, the application scenarios of DC charging piles will continue to expand.
